Specimen Gallery
Five-axis CNC milling for the whole Auralis material library — dry cutting for zirconia and polymers, wet cutting for glass ceramics and titanium, and a flagship that changes climate without stopping. From a chairside four-axis to an unattended eighteen-disc cell.
Six milling machines sit under the Auralis Mill name. Choose first by climate — dry, wet, or both — then by how much of the day you want the machine to run alone.
The flagship. Dry-mills zirconia before lunch, wet-mills lithium disilicate after — the switch is automatic: a purge-and-dry cycle clears and dries the chamber, with no draining and no wipe-down. A 60,000 rpm spindle, an 18-tool magazine and automatic ball calibration keep every margin true to the design.
Five-axis dry milling for the materials that fill a laboratory's day — zirconia, PMMA, wax and composites. No coolant to manage, no drying time to wait for: discs go in, frameworks come out ready for the furnace.
The clinic-sized wet mill. Four axes and a proprietary integrated coolant circuit in a cabinet that fits beside the chair — a PMMA or lithium disilicate crown in a typical cycle of about 19 minutes (indication-dependent), with feather-edge margins down to 0.09 mm at the machine limit; actual restoration accuracy depends on material and setup.
Dry and wet milling are not rivals — they answer to different physics. Choose by what you cut most, and let the 5X Duo cover the rest.
Pre-sintered zirconia mills like chalk and drinks no water — cutting it dry keeps the body compact, the margins crisp and the disc on the shortest path to the furnace. Polymers behave the same way: PMMA, wax, composites and PEEK cut clean and dry while extraction carries the dust away.
Glass ceramic is brittle and titanium holds heat — both need a coolant film at the cutting edge. Wet milling keeps lithium disilicate free of micro-cracks and flushes titanium chips away before they weld to the bur; the same circuit protects abutments and soft-metal work.
All six share the same CAM strategies and the same tooling ecosystem — the differences are climate, capacity and autonomy.
| Model | Axes | Process | Materials | Power | Dimensions (mm) | Weight |
|---|---|---|---|---|---|---|
| Mill 5X | 5-axis | Dry | Zirconia · composite · wax · PMMA | 1.2 kW | 530 × 650 × 750 | 145 kg |
| Mill 5X Wet | 5-axis | Wet | Lithium disilicate · zirconia · Ti abutments · soft metal | 1.5 kW | 535 × 655 × 720 | 170 kg |
| Mill 5X Duo | 5-axis | Dry / wet, auto-switch | Zirconia · PMMA · PEEK · wax · lithium disilicate · titanium | 2.5 kW | 525 × 700 × 784 | 150 kg |
| Mill 4X Chairside | 4-axis | Wet | PMMA · lithium disilicate ≤ 40 mm · prefab blanks | 1.0 kW | 525 × 390 × 540 | 85 kg |
| Mill 5X Auto | 5-axis + auto disc changer | Dry · 18-disc changer | Zirconia · PMMA · PEEK · wax | 1.8 kW | 932 × 730 × 855 | 260 kg |
| Mill 5X Metal | 5-axis | Water-cooled | Titanium · PMMA · lithium disilicate | 1.8 kW | 595 × 760 × 1,635 | 360 kg |
Special systems — 5X Duo: 60,000 rpm spindle, 18-tool magazine, automatic ball calibration, automatic purge-and-dry dry/wet switchover. 5X Auto: 18-disc changer, 12-tool changer, RFID disc recognition, remote monitoring. 4X Chairside: ≈ 19-minute cycle (typical, indication-dependent), proprietary integrated coolant circuit. 0.09 mm is a machine-capability limit; actual restoration accuracy depends on material and setup.
Zirconia, lithium disilicate, PMMA, PEEK and wax across the line; the 5X Metal tier also mills titanium for custom abutments. Material-specific strategies ship with the CAM templates.
Glass ceramics and titanium must be milled wet; zirconia and PMMA are typically milled dry. The dry-and-wet tier switches between both in one machine, which is the usual choice for labs running mixed materials.
Yes. It accepts standard 98 mm discs and open CAM files, and Auralis materials carry no machine lock — you can keep your existing disc inventory and workflows.
A typical zirconia crown mills in about 19 minutes with the standard strategy; time varies with geometry, material and finishing level. Ask us for a demonstration cut on your own case file.
Installation, training and CAM strategy support are available for partner laboratories and clinics across Southeast Asia — from a single chairside unit to an unattended milling cell.
