An additive workflow grown from light — a 29 μm 8K LCD engine for models, guides, splints and casting patterns, a one-station wash & cure, and a tested family of 405 nm dental resins. Print builds the workpiece; the mill keeps the restoration.
Printing is a chain, not a machine. Auralis Print pairs the build engine with post-processing and tested resins — so a workpiece leaves the platform and enters the clinic without a detour.
The build engine. A 10.3-inch 8K monochrome screen resolves 29 microns per pixel; auto-levelling, auto-feed and a heated build chamber keep every layer honest — splints tonight, guides tomorrow.
The finishing station. A sealed wash chamber lifts the uncured film away; dual-band UV on a 360° magnetic turntable then drives the cure to full depth — 2 to 90 minutes, dialled to the material.
The material family. Model, guide, temporary-crown and casting resins — each profile tuned on the Auralis engine and tested through the full wash-and-cure loop, so parameters are inherited, not guessed.
One digital file, two manufacturing lines. The division of labour is simple: geometry that must be grown belongs to Print; surfaces that must carry the bite belong to Mill.
Grows geometry from liquid resin, layer by layer. Models, guides, splints, denture bases and casting patterns — with the hollows, channels and undercuts no bur can reach.
40–60 mm/h, heated chamber, auto-feed — queue a build at night, wash and cure it in the morning.
29 μm XY accuracy and 8× anti-aliasing keep guide sleeves and model margins true to the plan.
Carves the final restoration from a solid ceramic blank. Zirconia, glass ceramic and PMMA — dense, sintered, load-bearing surfaces that only cutting can deliver.
Every surface that carries the bite — crowns, bridges, veneers — is milled, then fired in Auralis Sinter.
The same case moves between both lines — print the model to verify, mill the restoration to deliver.
| Property | Value |
|---|---|
| Light source | 405 nm UV array |
| Exposure screen | 10.3″ 8K monochrome LCD |
| Native resolution | 7680 × 4320 px |
| XY accuracy | 29 μm |
| Layer thickness | 0.01–0.1 mm |
| Build volume | 228 × 120 × 100 mm |
| Print speed | 40–60 mm/h |
| Chamber heating | 20–45 °C |
| Anti-aliasing | 8× |
| Levelling & feeding | Automatic |
| Footprint | 340 × 292 × 552 mm |
| Property | Value |
|---|---|
| Process | Wash + cure, one station |
| Wash chamber | 170 × 120 × 160 mm |
| Cure chamber | Ø165 × 200 mm |
| UV source | Dual-band |
| Rotary platform | 360° magnetic |
| Speed settings | 3 levels |
| Timer range | 2–90 min |
| Rated power | 96 W |
| Net weight | 6.5 kg |
All indications are tested on Auralis 405 nm resins through the full Print → Print Cure loop. Material-specific parameters ship with every bottle.
Demo prints, resin starter kits and full parameter sheets are available for partner labs and clinics across Southeast Asia.
