Specimen Gallery
The firing line of the digital lab. High-speed and standard furnaces built around one curve of heat — high-purity MoSi₂ elements climbing at up to 200 °C per minute, holding the peak to ±1 °C — so a milled white body becomes a dense ceramic restoration in a total cycle of as little as 40 minutes for light loads.
Every Auralis Sinter furnace belongs to one of three tiers. Choose by what you fire most — zirconia at full speed, zirconia at full volume, or glass ceramic under vacuum.
The speed tier. High-purity MoSi₂ elements climb at up to 200 °C per minute and hold 1530 °C for a 40-minute total flash cycle — same-day zirconia, from milled white body to dense ceramic, typically before the patient leaves (indication-dependent). Flash cycles are intended for small loads centred on single crowns; full-tray loads run on the standard program.
The volume tier. An elevator chamber that holds ±1 °C across double-stacked trays, running 24 programs day and night — the quiet workhorse of the high-volume lab.
The glass tier. A high-purity quartz muffle under vacuum below 35 mmHg, with two-stage programs for crystallization, staining and glaze — where lithium disilicate gets its final shine.
One line covers the full firing spectrum of the digital lab — glass-ceramic crystallization at 840 °C, conventional zirconia sintering between 1450 and 1530 °C, and a 40-minute total flash cycle at 1530 °C for light loads. Choose the furnace by the curve you run most.
| Program | Cycle | Peak |
|---|---|---|
| Standard sinter — all zirconia tiers | Conventional | 1450–1530 °C |
| Flash sinter — Sinter Flash (small loads, single-crown focused) | 40 min total · light load | 1530 °C |
| Crystallization — glass ceramic | Two-stage | 840–850 °C |
| Stain & glaze — porcelain & glass | Two-stage | ≤ 1200 °C |
Flash cycles pair with Auralis Zirconia Multi discs; crystallization and glaze programs serve the Auralis Glass line. Full firing curves ship with every furnace.
Choose by temperature ceiling, chamber style and throughput — the rest of the workflow stays the same.
| Property | Sinter Flash | Sinter Standard | Sinter Porcelain |
|---|---|---|---|
| Max temperature | 1650 °C | 1560 °C | 1200 °C |
| Chamber & elements | High-purity MoSi₂ | Elevator chamber | Quartz tube muffle |
| Ramp rate | ≤ 200 °C/min | — | 10–100 °C/min |
| Capacity | ≤ 30 units · ≤ 60 stacked | Double-layer stacking | Φ85 × 55 mm |
| Programs | 10 preset + 189 user | 24 | Two-stage programs |
| Final vacuum | — | — | < 35 mmHg |
| Power | 3 kW | ≤ 2 kW | 1200 W + 350 W |
| Dimensions | 420 × 568 × 816 mm | 370 × 530 × 780 mm | 325 × 420 × 560 mm |
| Weight | 73 kg | 50 kg | 25.5 kg |
Yes — for light loads such as single crowns and short bridges, the Flash furnace completes heating, holding and cooling in about 40 minutes end to end. Heavier loads should use the standard cycle.
Yes. With 24 programmable curves you can enter any manufacturer's recommended profile; peak temperature reaches 1650 °C with high-purity MoSi₂ elements, which covers mainstream zirconia systems.
If same-day cases drive your business, Flash pays for itself in turnaround speed. If you batch overnight sinters of full plates, the Standard elevator furnace with ±1 °C control is the workhorse; many labs eventually run both.
MoSi₂ elements need a periodic regeneration firing and a dry, vibration-free installation. The furnace prompts scheduled maintenance on screen, and our team walks you through the first service remotely.
Firing curves, tray kits and installation guidance are available for partner labs and clinics across Southeast Asia.
