Specimen Gallery
Titanium bonding bases that turn a milled zirconia crown into a screw-retained restoration. Ti-6Al-4V precision in Engaging and Non-Engaging geometries, with gingival heights from 0.5 to 4.0 mm — matched to the platforms of major implant systems.
Every Auralis Ti-Base starts from the same Ti-6Al-4V blank and the same bonding chimney. What changes is how it meets the implant — and how high the collar rises through the tissue.
The single-tooth base. An internal hex engages the implant connection and locks the crown against rotation — the standard choice for one-piece screw-retained crowns.
The multi-unit base. The hex floats free, so every base seats fully on its own implant even when the angles diverge — splinted bridges, bar-retained overdentures and full-arch frameworks.
One collar does not fit every sulcus. Six gingival heights let the crown margin follow the soft-tissue contour — subgingival in the aesthetic zone, supragingival where hygiene matters more. As a rule of thumb, the bonding interface should sit 0.5–1 mm subgingivally.
A Ti-Base is the metal half of a hybrid crown: the zirconia coping is cemented onto the titanium chimney, and the assembly seats directly onto the implant — no screw channel through fragile aesthetics, no cement line left subgingivally in the mouth.
Bonding takes place on the fully sintered, densified zirconia crown — the titanium base never enters any sintering or crystallization furnace. Post-sinter bonding with an MDP resin cement is the most common laboratory route.
Connection geometries are machined to the platform dimensions of the major implant systems placed across Southeast Asia — one Ti-Base family, no loyalty to a single implant brand required.
Brand names such as Dentium, Osstem, Straumann and ITI are trademarks of their respective owners and are used solely to indicate compatibility. Auralis products are aftermarket components and are not manufactured, endorsed or authorized by these companies. ITI (International Team for Implantology) is an academic organization, not a manufacturer.
| Property | Value |
|---|---|
| Material | Ti-6Al-4V titanium alloy, implant grade |
| Alloy standard | ASTM F136 (ELI) compliant |
| Surface | Precision-machined; micro-textured bonding chimney |
| Fit | Platform-matched to listed systems |
| In the box | Ti-Base + matched prosthetic screw |
| Sterilization | Steam autoclavable, 134 °C · delivered non-sterile |
The titanium-to-zirconia bond is a materials-science problem that has already been solved — mechanical retention at the surface, chemical retention in the cement. Three habits keep it that way.
Airborne-particle abrade the chimney (≈ 50 μm Al₂O₃), then steam-clean — mechanical retention starts at the surface.
Apply an MDP-containing metal primer or resin cement; seat the zirconia coping with firm pressure and remove the excess.
Keep the screw channel free of cement; at delivery, seal it with PTFE tape and composite after final torque.
Final torque of the prosthetic screw follows the matched system (typical range 15–35 Ncm) — always per the system manufacturer's IFU. A system reference card ships with the goods.
Compatibility charts, gingival-height selectors and sample kits are available for partner labs and clinics across Southeast Asia.
